HONDA GENIO
Green - Blue
Collaboration Black
Luggage fit for 14L
The large capacity of the
UBox (14L) can
accommodate more
luggage.
Front Shelf Charger
You can stay up to date and
do activities anywhere more
easily by using the Charger
to charge your gadgets.
Key Security with Seat
Open Button
More secure (reduces the
risk of theft) and easy to
open the U-Box by simply
pressing a button.
LED Headlights
A modern touch with
compact dimensions,
providing maximum
lighting when driving in all
conditions.
Digital Meter Panel
with Eco Indicator
More informative and
accurate with speedmeter,
odometer, fuel meter, eco
indicator, and Genio logo
that lights up. (*colors may
change at any time)
Ban Velg 12 inch
Equipped with tubeless
tires that add safety and
comfort when driving
with a trendy design.
Honda Genio Specification
| Engine | |
|---|---|
| Engine Type | 4 – Stroke, SOHC, eSP |
| Fuel System | Injection (PGM-FI) |
| Bore x Stroke | 47.0 x 63.1 mm |
| Transmission | Automatic, V-Matic |
| Compression Ratio | 10.0 : 1 |
| Maximum Power | 6.6 kW (9.0 PS) / 7,500 rpm |
| Maximum Torque | 9.3 N.m (0.94 kgf.m) / 6,000 rpm |
| Starter | Electric Starter and Kick Starter (CBS Type) |
| Clucth | Automatic, Centrifugal, Dry Type |
| Type | |
|---|---|
| Frame Type | Backbone – eSAF (enhance Smart Architecture Frame) |
| Front Suspension | Type Telescopic |
| Rear Suspension | Type Swing Arm with Single Shock Absorber |
| Front Tire Size | 80/90 - 14 M/C 40P Tubeless |
| Rear Tire Size | 80/90 - 14 M/C 40P Tubeless |
| Front Brake | Hydraulic Disc with Single Piston |
| Rear Brake | Drum |
| Braking System | Combi Brake System |
| Dimension | |
|---|---|
| Length X Width X Height | 1.862 x 694 x 1.061 mm |
| Seat height | 744 mm |
| Wheelbase | 1,251 mm |
| Lowest ground clearance | 150 mm |
| Empty weight | 92 kg (Tipe CBS) 93kg (Tipe CBS - ISS) |
| Capacity | |
|---|---|
| Fuel Tank Capacity | 4.2 L |
| Lubricating Oil Capacity | 0.65 Liter (Periodic Replacement) |
| Electricity System | |
|---|---|
| Electricity | MF 12V-3Ah |
| Ignition System | Full Transisterized |
| Spark Plug Type | NGK MR9C-9N |
