HONDA PCX 160
ABS & CBS Type
Roadsync Type
Multi Function Switch
Advanced technology to
operate the TFT Panel
Meter easily and
practically which helps
users in driving. *Only
on the RoadSync type
Multi Function Switch
A handy button feature
to give high beam signals
to other drivers. *Only
on RoadSync type
New Handle Bar Cover
Handlebars with covers
make the appearance
more luxurious and
classy
5 inch TFT Panel Meter
The full color indicator
panel is equipped with
5-inch TFT technology
with customizable display
and background color
and provides complete
information for the rider
including Honda
RoadSync, Tacho Meter,
Trip Meter, and Fuel
Consumption Information.
*Only on RoadSync type
USB Type C-Charger
Honda PCX is equipped
with a USB Type-C Charger
*maximum power 5V 3A.
Honda Smart Key
System
Advanced technology
innovation controlled by
remote, where no longer
requires a mechanical key
to start the engine and lock
the handlebars (keyless).
Integrated with Immobilizer,
Anti Theft Alarm security
system and Answer Back
System to make it easier
to find the position of the
motorbike in the parking
lot.
New LED Headlight
Design
Look more luxurious and
sharp with headlights that
use an LED lighting system
so they are brighter.
Anti Lock Braking
System (ABS)
Improves stability and
safety during braking,
preventing wheel locking
during sudden braking
(at high speed or slippery
road conditions). **Only
on ABS and Roadsync
types
More Comfortable Foot
Area
Driving anywhere feels
more comfortable with
a wider footrest area.
Subtank Rare Suspension
The rear suspension is
equipped with a tube to
get better and more
comfortable suspension
rebound performance.
*Only on RoadSync Type
New LED Taillight Design
The rear suspension is
equipped with a tube
to get better and more
comfortable suspension
rebound performance.
*Only on RoadSync Type
Extra Large 30 Liter
Luggage Box
A 30-liter capacity luggage
box equipped with a seat
retainer. Makes it easy to
carry items while driving
Honda PCX Specification
| Engine | |
|---|---|
| Engine Type | 4 Stroke, 4-Valve, eSP+ |
| Cooling System | Liquid Cooled |
| Fuel System | Injection (PGM-FI) |
| Stroke Volume | 156,9 cc |
| Bore x Stroke | 60 x 55,5 mm |
| Compression Ratio | 12 : 1 |
| Maximum Power | 11,8 kW (16 PS) / 8.500 rpm |
| Maximum Torque | 14,7 Nm (1,5 kgf.m) / 6.500 rpm |
| Transmission Type | Automatic , V - Matic |
| Starter | Electric Starter |
| Clucth | Automatic, Centrifugal, Dry Type |
| Oil Capacity | 0,8 L (Periodic replacement) |
| Type | |
|---|---|
| Frame Type | Double Cradle |
| Front Tire Size | 110/70 - 14 M/C Tubeless |
| Rear Tire Size | 130/70 - 13 M/C Tubeless |
| Front Brake | Cakram hidrolik - (Tipe CBS) Triple Pots Hydraulic, Combi Brake System |
| (Tipe ABS & RoadSync) Anti Lock Braking System | |
| Rear Brake | Hydraulic Disc |
| Braking System | Combi Brake System (CBS) & Anti-Lock Braking System (ABS) |
| Front Suspension | Type Telescopic |
| Rear Suspension | (CBS & ABS Type) Dual Rear Suspension / (RoadSync Type) Dual Rear Suspension with Tube |
| Dimension | |
|---|---|
| Length X Width X Height | 1.936 x 742 x 1.123 mm |
| Seat height | 764 mm |
| Wheelbase | 1.313 mm |
| Lowest ground clearance | 135 mm |
| Curb weight | 132 kg (CBS), 132 kg (ABS) & 133 kg (RoadSync) |
| Fuel tank capacity | 8,1 liter |
| Electricity System | |
|---|---|
| Electricity | MF 12V-5Ah |
| Ignition System | Full Transisterized |
| Spark Plug Type | NGK LMAR8L-9 |
| Charger Power | 5V, 2,1A |
