YAMAHA ALL NEW R15 CONNECTED
Powerfull155cc Engine With VVA
155 cc engine, Liquid Cooled, SOHC, 4 -Valves, Fuel Injection with VVA, a powerful engine that provides an extraordinary driving sensation.
Yamaha Motorcycle Connect
Communication Control Unit (CCU) technology is the first in Indonesian-made motorcycles and is connected to the Bluetooth-based Y-Connect (Yamaha Motorcycle Connect) application.
Yamaha All New R15 Connected Feature
Dual Channel Anti-Lock Braking System (ABS)
The dual channel ABS (Anti-Lock Braking System) system optimizes braking control.
Traction Control System
Technology designed to reduce the risk of rear tire slippage in all road surface situations during acceleration.
Assist & Slipper Clutch
The assist feature makes the clutch lighter, and the slipper clutch feature makes gear shifting smoother and acceleration faster.
Quick Shifter
A feature that allows the rider to shift up gears without pulling the clutch lever, thus speeding up and getting maximum acceleration.
M-Shaped Intake Duct with LED Projector Headlight
The front view with the distinctive R Series features an “M” shaped air duct in the style of the YZR-M1 and an LED Projector Headlight lighting system that maximizes the lighting system.
Twin Eyes LED Position Lights
The appearance of two “Day Time Running Light” lights that further emphasize the aggressive character of the latest generation of the R Series. YZR-M1 Styled Triple Clamp A feature that functions to provide a balance of strength and rigidity that not only creates excellent handling but its design is like that used on the MotoGP YZR-M1. YZF-R1 Styled Full Digital Speedometer YZF-M1 style speedometer.
Sporty Riding Position with Aerodynamic Design
A sporty and racing riding position with a fairing design that has good aerodynamics typical of R-DNA
Deltabox Frame
The strong and sturdy Deltabox frame provides more solid control.
Aluminum Rear Arm
The sturdy and lightweight Aluminum Banana Swing Arm provides maximum motorcycle control.
YZF-R1 Styled Full Digital Speedometer
YZF-R1 styled speedometer with LCD instrument and 2 display options “Track Mode” & “Street Mode” which can provide complete information to the rider.
Big Bike Engine Switch Off
The signature starter button of “Big Bike”. consists of l3in1 cut off/on and Starter Engine buttons.
Upside Down Suspension
Better handling, maximum control, and looks more dashing when driving.
Yamaha All New R15 Connected Specification
| Engine | |
|---|---|
| Engine Type | Air cooled 4-Stroke SOHC, 4 Valve, VVA |
| Cylinder | Single Cylinder |
| Volume Cylinder | 155.09 cc |
| Bore × Stroke | 58,0 x 58,7 mm |
| Compression Ratio | 11,6 : 1 |
| Max. Power | 14,2 kW / 10.000 rpm |
| Max. Torque | 14,7 Nm / 8,500 rpm |
| Starter System | Eletric Starter |
| Lubricant System | Wet Sump |
| Oil Capacity | 1,05L (Total); 0,85L (Berkala); 0,95L (Chanage Filter Oil) |
| Fuel System | Fuel Injection |
| Clucth System | Dry, Centrifugal Automatic |
| Transmission System | 1-N-2-3-4-5-6 |
| Frame & Footer | |
|---|---|
| Frame Type | Deltabox |
| Front Suspension Type | Telescopic Fork (Inverted) |
| Rear Suspension Type | Link Monoshock |
| Front Tires | 100/80-17M/C 52P |
| Rear Tire | 140/70-17M/C 66S |
| Front Brake | Disc Brake |
| Rear Brake | Disc Brake |
| Dimension | |
|---|---|
| Dimension | 1990 x 725 x 1135 mm |
| Wheelbase | 1325 mm |
| Ground clearance | 170 mm |
| Seat Height | 815 mm |
| Curb weight | (All New R15M) 140 Kg |
| 137 Kg (All New R15) | |
| Fuel Capacity | 11 L |
| Electricity System | |
|---|---|
| Battery | GTZ4V/YTZ4V (All New R15) |
| YTZ6V (All New R15M) | |
| Spark Plug | NGK/LMAR8A-9 |
| Ignition System | TCI |
