YAMAHA GEAR 125
5 Years Warranty
5 Year/50,000 Km warranty covers Frame*, FI components, DiASil Cylinder & Forged Piston**. *Only valid for Yamaha matic motorcycles. **Conditions and conditions apply, see Service and Warranty Book.
Answer Back System
A feature that helps you find your motorbike when it is parked. Press 1x on the remote, the motorbike will sound and the turn signal will flash.
Yamaha Gear 125 Feature
Blue Core 125cc with SMG
New generation of 125 cc bluecore engine with SMG (Smart Motor Generator) technology so that the engine sound is smoother when turned on and provides an EFFICIENT, Powerful & Reliable driving experience, which is also equipped with an eco indicator.
Tough Design
With the New Design of Yamaha GEAR, Enjoy Riding with a Different Sensation that Makes Your Appearance Look Tough.
Footrest for Children
Additional footrest for small children that provides comfort when riding tandem.
Double Hook
Additional Hook that makes it easier to carry lots of luggage.
Spacious Luggage
Spacious and roomy luggage is suitable for your day full of activities.
Electric Power Socket
More practical with the “Electric Power Socket” to charge the rider’s gadgets.
Tubeless Tires with Wide Tread
Front tire size 80/80 – 14″, Rear tire size 100/70 – 14″ provides a comfortable driving experience when maneuvering.
Side Stand Switch
Mesin tidak dapat dinyalakan ketika standard samping digunakan.
Stop & Start System
Advanced feature with an automatic system that stops or turns off the engine when stopped for more than 5 seconds and starts or turns on again when the gas lever is turned.
Yamaha Gear 125 Specification
| Engine | |
|---|---|
| Engine Type | Air Cooled 4-Stroke,SOHC |
| Volume Cylinder | 125 cc |
| Cylinder | Single Cylinder |
| Bore × Stroke | 52,4 x 57,9 mm |
| Compression Ratio | 9,5 : 1 |
| Max. Power | 7,0 kW / 8000 rpm |
| Max. Torque | 9,5 Nm/ 5500 rpm |
| Starter System | Eletric Starter & Kick Starter |
| Lubricant System | Wet Sump |
| Oil Capacity | Total : 0.84 L ; Periodic : 0,80 L |
| Fuel System | Fuel Injection |
| Clucth System | Dry, Centrifugal Automatic |
| Transmission System | V-Belt Automatic |
| Frame & Footer | |
|---|---|
| Frame Type | Underbone |
| Front Suspension Type | Telescopic Fork |
| Rear Suspension Type | Unit Swing |
| Front Tires | 80/80-14M/C (43P) |
| Rear Tire | 100/70-14M/C (51P) |
| Front Brake | Disc Brake |
| Rear Brake | Drum disk |
| Dimension | |
|---|---|
| Dimension | 1870 mm X 685 mm X 1060 mm |
| Wheelbase | 1260 mm |
| Ground clearance | 135 mm |
| Seat Height | 750 mm |
| Curb weight | 96 Kg (Variants S) |
| 95 Kg (Tipe Standard) | |
| Fuel Capacity | 4,2 L |
| Electricity System | |
|---|---|
| Battery | YTZ6V (Variant S) |
| YTZ4V/GTZ4V/NTZ4V (Tipe Standard) |
|
| Spark Plug | NGK/ CR6HSA |
| Ignition System | TCI |
