YAMAHA GRAND FILANO
5 Years Warranty
5 Year/50,000 Km warranty covers Frame*, FI components, DiASil Cylinder & Forged Piston**. *Only valid for Yamaha matic motorcycles. **Conditions and conditions apply, see Service and Warranty Book.
Yamaha Motorcycle Connect
Always-on connection with Communication Control Unit (CCU) technology, connecting the motorcycle to a smartphone via the Y-Connect application. *Only available on the Grand Filano LUX Version
Yamaha Grand Filano Feature
Luxury & Premium Design
Look more classy with a luxurious and elegant design!
Digital Speedometer with TFT Sub Display
First in its class! Digital speedometer that is increasingly informative with colored displays and animations such as Welcome-Goodbye Message, Odometer, Fuel Consumption, & Power Assist Indicator.
All New LED Lighting System
The entire lighting system uses LEDs such as Diamond-Shaped LED Headlights, Unique LED Position Lights, Front & Rear LED Turn Signals, LED Taillights, and LED Trunk Lights.
Premium Seat with Embroidery Style
A more classy seat design with premium colors and unique embroidery textures.
Blue Core Hybrid 125cc
The latest generation Blue Core 125cc engine that provides a more powerful, environmentally friendly and reliable riding experience. Equipped with Electric Power Assist Start which makes initial acceleration more powerful and smooth especially on uphill and when riding double.
Smart Front Fuel
Refueling is more practical without having to open the seat.
Spacious Luggage 27L with LED Lamp
Spacious 27L luggage equipped with LED lights to accommodate various riding equipment and your fashion items!
Smart Key System
Driving is more practical with a sophisticated keyless system, equipped with the Answer Back System feature to make it easier for drivers to find their motorbike parking locations.
USB Socket
Communication is always connected via the charging feature on the rider’s gadget.
Spacious Front Pocket
More practical to carry items with large storage space options.
Hazard Lamp
To give a sign in an emergency situation (according to Law no. 22 of 2009 on traffic regulations, article 121 paragraph 1)
Wide Tire and Tubeless
The size of the front and rear tires is 110/70 – 12″ to provide driving comfort.
Convenience Footstep
Wider footstep design for comfort when riding double.
Yamaha Grand Filano Specification
| Engine | |
|---|---|
| Engine Type | Liquid cooled 4-stroke, SOHC |
| Cylinder | Single Cylinder |
| Bore × Stroke | 52,4 x 57,9 mm |
| Compression Ratio | 11,xd0 : 1 |
| Volume Cylinder | 124,86 cc |
| Max. Power | 6,1 kW / 6.500 rpm |
| Max. Torque | 10,4 Nm / 5.000 rpm |
| Starter System | Eletric Starter |
| Oil Capacity | 0,84 L |
| Fuel System | Fuel Injection |
| Lubricant System | Wet Sump |
| Clucth System | Single Dry, Clutch |
| Transmission System | V-Belt Automatic |
| Frame & Footer | |
|---|---|
| Frame Type | Underbone |
| Front Suspension Type | Telescopic |
| Rear Suspension Type | Unit Swing |
| Front Tires | 110/70-12 47L |
| Rear Tire | 110/70-12 47L |
| Front Brake | Disc Brake |
| Rear Brake | Drum disk |
| Dimension | |
|---|---|
| Dimension | 1820 x 685 x 1155 mm |
| Wheelbase | 1280 mm |
| Ground clearance | 125 mm |
| Seat Height | 790 mm |
| Curb weight | 100 Kg |
| Fuel Capacity | 4,4 L |
| Electricity System | |
|---|---|
| Battery | YTZ6V |
| Spark Plug | CR6HSA |
| Ignition System | TCI |
