YAMAHA MX KING 150
150cc FI, Engine Liquid Cooled System
Racing engine technology that maximizes performance with a 4 valve 150cc Fuel Injection engine equipped with Forged Piston, DiAsil Cylinder and Liquid Cooled System.
Light Frame Design
More agile with Light Frame Design. Comes with a sporty riding position equipped with Mono Shock suspension at the rear and foldable rider footrests make it more comfortable in maneuvering & cornering.
Yamaha MX King 150
Wide Tubeless Tire
With the widest tubeless tire in its class, equipped with a 17 inch rim design, the MX KING looks even sportier and has a Double Disk Brake that maximizes braking and safety while driving.
Hazard Lamp
To provide a sign in an emergency situation, according to Law no. 22 of 2009 on traffic regulations, article 121 paragraph 1.
New Graphic Design
Has a symmetrical and increasingly sporty graphic design with thick lines and inspired by the concept of bold colored downforce combined with bright accents for a speedy impression which is a strong characteristic of the MX King 150.
LED Head Light
Sporty style design 3 LED ( 2 Low Beam, 1 High Beam ) Head Light memberikan penerangan maksimal saat berkendara.
Full Digital Speedometer
Appears with new technology with a full LCD speedometer that is modern and informative for drivers.
Yamaha MX King 150 Specification
| Engine | |
|---|---|
| Engine Type | Liquid cooled, 4 stroke, SOHC, 4 valves |
| Cylinder | Single Cylinder/ Upright |
| Volume Cylinder | 149,79 cc |
| Bore × Stroke | 57,0 x 58,7 mm |
| Compression Ratio | 10,4 : 1 |
| Max. Power | 11,3 kW / 8500 rpm |
| Max. Torque | 13,8 Nm / 7000 rpm |
| Starter System | Elektrik Starter & Kick Starter |
| Lubricant System | Wet Sump |
| Fuel System | Fuel Injection |
| Clucth System | Wet, Manual Clutch, Multiplate |
| Oil Capacity | Total = 1.15 L Periodic = 0.95 L Replace oil filter = 1.00 L |
| Transmission Type | Manual |
| Transmission | 1-N-2-3-4-5 |
| Frame & Footer | |
|---|---|
| Frame Type | Backbone |
| Front Suspension Type | Telescopic |
| Rear Suspension Type | Monoshock |
| Front Tires | 90/80-17M/C 46P |
| Rear Tire | 120/70-17M/C (58P) |
| Front Brake | Disk Brake |
| Rear Brake | Disk Brake |
| Dimension | |
|---|---|
| Dimension | 1985 mm X 670 mm X 1100 mm |
| Wheelbase | 1290 mm |
| Ground clearance | 155 mm |
| Seat Height | 795 mm |
| Curb weight | 118 kg |
| Fuel Capacity | 4,2 L |
| Engine | |
|---|---|
| Spark Plug Type | NGK/CR8E |
| Battery | GTZ4V / YTZ4V |
| Ignittion Sistem | TCI |
